SDEC SDEC SC13G420D2 diesel generator sets features:
• Engine include air, fuel, oil filters, starting motor and charge alternator etc.
• Brushless AC alternator, single bearing, flange connection, with AVR
• Radiator with engine driven fan mounted on skid
• Channel steel base frame, <550KW base 8hrs mounted fuel tank as standard
• Anti-vibration pads between engine/alternator and base frame
• Circuit breaker 3P as standard, 4P optional
• Auto control panel
• Start battery with connecting cable and floating battery charger
• Flexbile pipe, exhaust elbow, industrial silencer etc.
• Standard tools kit
• Electric drawing, test report ,operation & maintaince manual of generator etc.
•Optional soundproof/Container canopy, ATS cabinet, remote control panel, synchronization panel, movable trailers, heat exchanger, remote horizontal water tank system, external fuel tank, etc
| Manufacturer | Changsha Mingbang Intelligent Technology Co.Ltd | | Model | MB-S250 | | Prime Power | 250KW/312.5KVA | | Standby Power | 280KW/350KVA | | Power Factor | COSΦ=0.8(lagging) | | Max. Output current | 450 A | | Genset Weight | 2450KG | | Length x Width x Height (Engine) (mm) | 3000×1160×1700 | | Voltage | 400/230 | | Frequency | 50HZ | | Engine Specification | | Brand | SDEC | | Model | SC13G420D2 | | Rated speed | 1500rpm | | Prime Power | 280KW/350KVA | | Standby Power | 308KW/385KVA | | Fuel Consumption | <=200g/KW.H | | Lube oil capacity | 33L | | Bore (mm) x Stroke (mm) | 135×150 | | Compression ratio | 17:1 | | Displacement (litre) | 12.88L | | Coolant capacity, L | / | | Configuration | 6 in line ,four-stroke, Turbocharged, Charge Air Cooled | | Cooling | Liquid Cooled | | Governor type | Electronic | | Starting voltage | 24 Volts DC | | Filtration system | Air Filter/Fuel Filter/Oil Filter | | Alternator Specification | | Manufacturer | Changsha Mingbang Intelligent Technology Co.Ltd | | Model | MBC4C | | Voltage Regulator | AVR | | Voltage adjust range | ±1% | | Rated Voltage/Frequency/Factor | 400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire | | Steady-state Frequency | 5% | | No-load Voltage Adjust Range | >=95%-105% | | Insulation Class | H | | IP Protection | 22 | | Excitation Type | Blushless | | | |
Diesel Generators Sets 300kva 250kw Air Cooled Super Silent Diesel Generator Super Silent Generator Set
Painting materials
rust removing in pickling tank(10minutes)------unoil(30mins)-----rinsing(3mins)----watch setting(10mins)----rinsing(5mins)-----parkerising(20mins)----rinsing----blow dry-----stoving----pylons----spray paint(adopt static flame paint)-----Oven(170degree/20mins)-----draw a charge---inserting coil.
Painting material is powder, pretreatment takes 50 minutes, complete line paint takes 2.5hours.
Our factory
Mingbang power is the professional manufacturer of power generator, light tower and air compressor in China. We provides a complete line of generators for commercial,industrial and residential application.We specialize in providing a wide range of well known and trusted brands of diesel generators, supplying generators from 5kw to 2000kw at competitive prices.
Besides generators, we also product the refer product include lighting towers and air compressor. At the same time, we also provide the reference electrical products, include ATS, Synchronization system & switch gear.
More details for diesel generator sets ,please contact us any time
Your further inquiry will be welcome!!
